Incline Innovation: The ADA Ramp Trigonometry Challenge
Created byBenton Fletcher
1 views1 downloads

Incline Innovation: The ADA Ramp Trigonometry Challenge

Grade 10Math20 days
In this project, 10th-grade students act as urban design consultants to engineer ADA-compliant ramps that ensure safety and accessibility in public spaces. By applying trigonometric ratios and the properties of similar triangles, students analyze real-world 'fail' sites and calculate precise measurements for legal angles of inclination. The experience culminates in the development of professional-grade blueprints and a technical memorandum that mathematically justifies their designs for community-wide use.
TrigonometryADA ComplianceGeometric ModelingUrban DesignSimilar TrianglesAccessibilityEngineering
Want to create your own PBL Recipe?Use our AI-powered tools to design engaging project-based learning experiences for your students.
📝

Inquiry Framework

Question Framework

Driving Question

The overarching question that guides the entire project.How can we, as urban design consultants, use trigonometric ratios to engineer blueprints for local public spaces that satisfy ADA safety regulations and promote community-wide accessibility?

Essential Questions

Supporting questions that break down major concepts.
  • How do the properties of similar right triangles allow us to define and use trigonometric ratios?
  • In what ways does the angle of inclination dictate the ratio of side lengths in a right triangle?
  • How can we use sine, cosine, and tangent to calculate measurements that are difficult to measure physically?
  • How does the mathematical concept of 'slope' translate to the trigonometric concept of 'tangent' in real-world construction?
  • How do ADA (Americans with Disabilities Act) regulations use geometry to ensure safety and equity in public spaces?
  • What mathematical evidence is required to prove that a blueprint meets specific safety and legal standards?

Standards & Learning Goals

Learning Goals

By the end of this project, students will be able to:
  • Apply trigonometric ratios (sine, cosine, and tangent) to solve for unknown side lengths and angles in right triangle models of ADA-compliant ramps.
  • Explain the relationship between the slope of a ramp and the tangent of its angle of inclination, using mathematical evidence to ensure compliance with ADA standards.
  • Develop detailed, scale blueprints of public spaces that demonstrate how similarity in right triangles allows for consistent trigonometric calculations across different sizes of structures.
  • Evaluate real-world environments for accessibility and propose mathematically-sound modifications that promote community equity and safety.
  • Construct formal arguments and proofs using the properties of similar triangles to justify why specific trigonometric ratios remain constant for a given angle.

Common Core State Standards (Math)

CCSS.Math.Content.HSG.SRT.C.6
Primary
Understand that by similarity, side ratios in right triangles are properties of the angles in the triangle, leading to definitions of trigonometric ratios for acute angles.Reason: This is the foundational math standard for the project. Students must understand how similarity creates the ratios they will use to design their ramps.
CCSS.Math.Content.HSG.SRT.C.8
Primary
Use trigonometric ratios and the Pythagorean Theorem to solve right triangles in applied problems.Reason: The core task of the project is applying these ratios to ensure ramps meet specific ADA height and length requirements in a real-world design context.
CCSS.Math.Content.HSG.SRT.B.4
Secondary
Prove theorems about triangles. Theorems include: a line parallel to one side of a triangle divides the other two proportionally, and conversely; the Pythagorean Theorem proved using triangle similarity.Reason: Students will use the proportional nature of triangles to justify their blueprint designs and prove that their models scale correctly.
CCSS.Math.Content.HSG.MG.A.1
Supporting
Use geometric shapes, their measures, and their properties to describe objects (e.g., modeling a tree trunk or a human torso as a cylinder).Reason: Students are translating real-world physical spaces into geometric models and blueprints to analyze accessibility.

Common Core State Standards (Mathematical Practice)

CCSS.Math.Practice.MP4
Supporting
Model with mathematics.Reason: As a PBL experience, students are using mathematical tools to solve a complex, real-world community problem regarding urban design and civil rights.

Entry Events

Events that will be used to introduce the project to students

The Viral Fail Audit

Students view a curated 'fail' reel of dangerously steep ramps from social media and local news. They are challenged to use trig ratios to determine which ones are 'death traps' and calculate the exact dimensions needed to make them legal.
📚

Portfolio Activities

Portfolio Activities

These activities progressively build towards your learning goals, with each submission contributing to the student's final portfolio.
Activity 1

The ADA Slope Investigator

Students act as 'Compliance Officers' to translate building codes into mathematical constraints. The ADA requires a 1:12 slope (1 inch of rise for every 12 inches of run). Students will use the tangent ratio to determine the exact angle of inclination for this slope. They will then practice solving for 'Run' (horizontal distance) and 'Ramp Length' (hypotenuse) given various 'Rise' (vertical height) measurements from the 'Fail Reel' entry event.

Steps

Here is some basic scaffolding to help students complete the activity.
1. Identify the 'Rise' (Opposite) and 'Run' (Adjacent) in the ADA 1:12 ratio.
2. Use the inverse tangent function [tan⁻¹(1/12)] to calculate the maximum legal angle of a ramp.
3. Solve for the hypotenuse (the actual length of the ramp surface) using the sine ratio or Pythagorean Theorem for a standard 6-inch curb.
4. Create a 'Quick-Reference Chart' for contractors that lists the required ramp length and horizontal run for rises ranging from 2 to 30 inches.

Final Product

What students will submit as the final product of the activityThe 'ADA Math Decoder Ring'—a reference guide that includes the derivation of the 4.76-degree angle and a set of solved triangle problems for common curb heights (6-inch, 12-inch, and 18-inch rises).

Alignment

How this activity aligns with the learning objectives & standardsHSG.SRT.C.8: Use trigonometric ratios to solve right triangles in applied problems. This activity bridges the gap between the ADA's '1:12 slope' requirement and the trigonometric concept of tangent.
Activity 2

Site Survey & Geometric Modeling

Students will transition from theoretical math to physical modeling. They will select a 'fail' site from the entry event or a local community spot that lacks accessibility. Using a clinometer (which they can build or use via a smartphone app), they will measure the height of the obstacle and the available ground space. They will then model this space as a right triangle to determine if a compliant ramp can even fit in the existing environment.

Steps

Here is some basic scaffolding to help students complete the activity.
1. Choose a local site or an image of a 'fail' site that needs an ADA ramp.
2. Measure or estimate the vertical 'Rise' needed to reach the entrance.
3. Measure the available 'Runway' (horizontal space) to see if a 1:12 ramp will fit without hitting obstacles like sidewalks or streets.
4. Sketch a geometric model of the site, labeling the known constraints and the unknown variables (like required ramp length).

Final Product

What students will submit as the final product of the activityA 'Site Feasibility Study' containing a photo of the location overlaid with a geometric right-triangle model and initial feasibility calculations.

Alignment

How this activity aligns with the learning objectives & standardsHSG.MG.A.1: Use geometric shapes and their measures to describe objects. This activity focuses on modeling real-world physical spaces using right triangles.
Activity 3

The Master Blueprinter's Defense

In this final portfolio activity, students create a professional-grade blueprint for their chosen site. The blueprint must include a top-down view and a side-profile view (the right triangle). Critically, students must provide a 'Technical Memorandum' that uses trigonometric proofs to guarantee to the 'City Council' that the design is 100% ADA compliant. This includes proving that their scaled blueprint is similar to the actual proposed construction.

Steps

Here is some basic scaffolding to help students complete the activity.
1. Select a scale (e.g., 1 inch = 1 foot) and draw a precise side-profile of the proposed ramp using drafting tools or digital software.
2. Label all angles and side lengths, showing the trigonometric equations used to find them (Sine, Cosine, and Tangent).
3. Incorporate 'Landing Platforms' if the ramp is long, calculating the total length needed including these flat sections.
4. Write a formal 'Proof of Compliance' that explains how the properties of similar triangles ensure the full-scale ramp will have the same safe angle as the blueprint.

Final Product

What students will submit as the final product of the activityThe 'Incline Innovation Blueprint Package,' featuring a scale technical drawing, trig calculations for all sides/angles, and a written mathematical justification for safety compliance.

Alignment

How this activity aligns with the learning objectives & standardsHSG.SRT.B.4: Prove theorems about triangles. HSG.SRT.C.8: Solve right triangles in applied problems. This activity requires students to synthesize all previous steps into a formal design and mathematical justification.
🏆

Rubric & Reflection

Portfolio Rubric

Grading criteria for assessing the overall project portfolio

Incline Innovation: ADA Ramp Challenge Portfolio Rubric

Category 1

Mathematical Modeling & Calculation

Focuses on the mathematical precision and modeling skills required to translate building codes into geometric constraints.
Criterion 1

Trigonometric Accuracy & Application

Assessment of the student's ability to use sine, cosine, and tangent ratios, as well as inverse functions, to solve for unknown sides and angles in ADA-compliant ramp designs.

Exemplary
4 Points

Calculations are flawlessly executed across all scenarios (6, 12, 18-inch rises). Demonstrates sophisticated mastery by correctly deriving the 4.76-degree angle and applying multiple trigonometric methods (e.g., using both Sine and the Pythagorean Theorem) to verify results.

Proficient
3 Points

Calculations for sine, cosine, and tangent are accurate with only minor notation errors. Correctly identifies the inverse tangent for the 1:12 slope and provides clear evidence of solving for both run and hypotenuse in standard scenarios.

Developing
2 Points

Calculations show emerging understanding but contain inconsistent errors in side identification (opposite vs. adjacent) or calculator usage. Some required scenarios in the Quick-Reference Chart are incomplete or inaccurate.

Beginning
1 Points

Struggles to identify the correct trigonometric ratios for given sides. Calculations for the ramp angle or side lengths are missing or fundamentally incorrect, showing a lack of understanding of right triangle properties.

Criterion 2

Geometric Modeling & Site Analysis

Evaluates the student's ability to translate real-world physical spaces and 'fail' sites into geometric models (right triangles) for analysis.

Exemplary
4 Points

The geometric model is a highly precise representation of the site, accounting for complex constraints. The Feasibility Study provides sophisticated mathematical evidence for why a compliant ramp will or will not fit, including potential modifications.

Proficient
3 Points

Successfully models a real-world site as a right triangle with accurate 'Rise' and 'Run' measurements. The feasibility study uses these measurements to logically determine if a 1:12 slope is possible within the available space.

Developing
2 Points

The geometric model is present but lacks specific site measurements or uses estimated data that reduces accuracy. The connection between the physical site and the right triangle model is inconsistent.

Beginning
1 Points

The model is incomplete or fails to accurately reflect the physical constraints of the site. Measurements are missing or do not relate to the geometric properties of a right triangle.

Category 2

Design Synthesis & Communication

Evaluates the student's ability to synthesize calculations into a final professional product and defend their design choices using mathematical reasoning.
Criterion 1

Technical Drafting & Scaling

Assessment of the student's ability to create a professional-grade, scale blueprint that includes side profiles and top-down views with precise labeling.

Exemplary
4 Points

The blueprint is of professional quality, utilizing a consistent and clearly labeled scale. Includes advanced features like landing platforms for long runs, with all dimensions and angles verified through trigonometric equations.

Proficient
3 Points

The blueprint is clearly drawn to scale with all sides and angles labeled. Side-profile and top-down views are consistent with the trigonometric calculations provided in the Technical Memorandum.

Developing
2 Points

The blueprint is drawn but the scale is inconsistent or difficult to follow. Some labels for angles or side lengths are missing, making the design difficult to verify against ADA standards.

Beginning
1 Points

The drawing is not to scale or lacks the detail required for a blueprint. Geometric shapes do not accurately represent the intended ramp design.

Criterion 2

Mathematical Justification & Proof

Evaluates the formal written defense of the design, specifically the use of geometric proofs and similarity to justify ADA compliance and safety.

Exemplary
4 Points

The Technical Memorandum provides a sophisticated proof of compliance. It eloquently uses the properties of similar triangles to guarantee that the scale model and final construction will share the same safe angle, connecting the concept of 'slope' to 'tangent' flawlessly.

Proficient
3 Points

Provides a clear mathematical argument for safety compliance. Successfully explains how the 1:12 ratio translates to a specific angle and uses similar triangle properties to justify the blueprint's validity.

Developing
2 Points

The justification is primarily descriptive rather than mathematical. Mentions ADA standards but lacks a clear explanation of how similarity or trigonometric ratios ensure the safety of the full-scale design.

Beginning
1 Points

The memorandum lacks mathematical evidence or fails to address the concept of compliance. The argument does not connect the blueprint design to geometric principles or legal safety standards.

Reflection Prompts

End-of-project reflection questions to get students to think about their learning
Question 1

How confident do you now feel in your ability to apply trigonometric ratios (sine, cosine, and tangent) to solve real-world engineering and design problems?

Scale
Required
Question 2

Throughout the 'Incline Innovation' project, which part of the 'Urban Design Consultant' role required the most significant shift in how you think about geometry?

Multiple choice
Required
Options
Translating the ADA 1:12 building code into a trigonometric angle (The ADA Slope Investigator)
Modeling physical site constraints into a geometric right triangle (Site Survey)
Using scale and similarity to translate calculations into a blueprint (Master Blueprinter)
Writing the formal proof of compliance to justify the safety of the design
Question 3

Explain the relationship between 'slope' and the 'tangent ratio.' How does the geometric principle of triangle similarity guarantee that a ramp built from your blueprint will be safe for a wheelchair user, even though the drawing is much smaller than the actual ramp?

Text
Required
Question 4

In the 'Viral Fail Audit,' you saw examples of ramps that were dangerous 'death traps.' Based on your work, why is mathematical accuracy more than just a grade when it comes to ADA compliance? How has this project changed your perspective on accessibility in your own neighborhood?

Text
Required
